Top Tube Length
|
20.5” |
Chain Stay Length
|
13.75” |
Head Tube Angle
|
75º |
Seat Tube Angle
|
72º |
Frame
|
Chromoly front triangle |
Fork
|
Hi-ten steel w/ chromoly steerer tube, built-in bearing race, internally threaded pre-load bolt, tapered legs |
Headset
|
Sealed integrated |
Stem
|
DK Jump top load, 53mm reach |
Handlebar
|
8.8” rise, 100% chromoly |
Grips
|
DK Proxy w/ press-in bar plugs |
Brake Lever
|
Wise alloy |
Brake
|
Wise alloy U-brake |
BB
|
19mm sealed Mid |
Sprocket
|
DK 25T, steel |
Chain
|
KMC Z-510 |
Cranks
|
Wise tubular chromoly 3-piece, 170mm, 8-spline spindle |
Pedals
|
DK Blender PC platform |
Front Hub
|
Alloy, fully sealed, 3/8” axle |
Rear Hub
|
Alloy, fully sealed, 14mm axle, 9T driver |
Rims
|
Wise Rectrix1, single wall, 36mm wide, 36-hole |
Tires
|
Kenda 2.3”, 60psi |
Seat
|
DK 1-piece padded seat/post combo |
Seat Post
|
25.4mm, alloy |
Seat Post Clamp
|
Integrated |
Features
|
3D head tube badge |
Weight
|
26.4 lbs |
